規格參數/Machine parameters：
Model | MLG-1200 | MLG--1500 | MLG--2000 | MLG--2500 |
焊點數量 Number of electrodes | 24 | 31 | 41 | 48 |
最大寬度 Max. Mesh width |
1200mm |
1500mm |
2000mm |
2500mm |
鋼筋直徑 Wire diameter | 2.5--5.0mm | 2.5--5.0mm |
2.5--5.0mm |
2.5--5.0mm |
網長 Max. mesh length |
As per required |
As per required |
As per required |
As per required |
橫筋間距 Cross wire space |
50--300mm |
50--300mm |
50--300mm |
50--300mm |
縱筋間距 Line wire space |
50--300mm |
50--300mm |
50--300mm |
50--300mm |
焊接變壓器 Welding transformer |
160KVA*3PCS | 160KVA*4PCS |
160KVA*5PCS |
160KVA*6PCS |
焊接速度 Welding speed | 40--70次/分鐘 40--70times/min | 40--70次/分鐘40--70times/min | 40--70次/分鐘 40--70times/min | 40--70次/分鐘 40--70 times/min |
控制方式 Control system | PLC可編程控制 PLC programmable controller | PLC可編程控制 PLC programmable controller | PLC 可編程控制 PLC programmable controller | PLC 可編程控制 PLC programmable controller |
拉網方式 Method of pull mesh | 通過伺服電機 By servo motor | 通過伺服電機 By servo motor | 通過伺服電機 By servo motor | 通過伺服電機 By servo motor |
送經絲方式 Method of Send line wire | 盤絲入料自動送經 Line wire form coil | 盤絲入料自動送經 Line wire form coil
| 盤絲入料自動送經 Line wire form coil
| 盤絲入料自動送經 Line wire form coil
|
